125KHZ T5577 RFID Access Control Epoxy Tag

125KHZ T5577 RFID Access Control Epoxy Tag

Product Code: ATA5577 smart card ----0014
Availability: In Stock

Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: OEM
  • Model Number: ATA5577 smart card ----0014
  • Commodity: 125khz t5577 epoxy tag
  • Material: PVC,ABS,PET
  • Design: AI.CDR.PSD.PS.
  • Size: 85.5*54*0.84 mm
  • Color: CMYK
  • Chips: T5577
  • Surface: glossy,matte or frosted
  • Special Craft: spot UV printing
  • Data encoding: yes
  • Application: Hotel key cards ,Access control cards

Packaging & Delivery

Packaging Details: 1. White box: 22 cm x 9 cm x 6cm, 200 pieces/ box
2. Carton: 48 cm x 22.5 cm x 14cm, 10 boxes/ carton.
Delivery Detail: 5-7 days after the receipt of payment

Specifications

125khz t5577 epoxy tag
1.Factory Price
2.24 hours online service
3.Shelf Life:1 year.

125KHZ T5577 RFID Access Control Epoxy Tag



-------------------------------------------------------------------------------------------------------------------------------



Size:85.5*54*0.84mm or customize

Material:PVC

Chip:ATAT5577 / CET5577

Craft:Both side full color printing,Series number,Sigature panel ,Hologram ,Magnetic stripe etc...

Moq :200pcs

Available:Keyfob tag ,Smart cards,Blank smart cards



-------------------------------------------------------------------------------------------------------------------------------------



Description



Atmel® offers a broad range of RFID devices for contactless read/write RF identifi cation systems, delivered as die on wafer, die in tray, die on tape, micromodule, or complete transponder in a plastic package. Our low-frequency IDIC® products (100 to 150 kHz) with different security levels are flexible for all kinds of applications, easy to design-in and well-matched.



---------------------------------------------------------------------------------------------------------------------------------------


Typical Applications



Access Control ISO Cards, Key Fobs, and Coins
A. Asset Management
B.Animal Identifi cation
(Supporting ISO 11784/11785 – FDX-B)
– Livestock Tracking
– Pigeon Racing Tags
 Waste Management

ISO 11784/11785 (Non-Animal Mode)

A.Laundry
B. Manufacturing and Logistics

– Material Handling
– Recycling
– Cylinder Tracking



---------------------------------------------------------------------------------------------------------------------------------------



Features

Contactless 100 kHz to 150 kHz Read/Write
Identifi cation IC (IDIC)
Version M1 Standard Pads
 Version M2 Mega Pads
 Backwards Compatible to e5550/51 in Most
Common Modes
 Backwards Compatible to T5557 and ATA5567
 On-Chip Capacitor 0 pF, 75 pF, 250 pF, or 330 pF, trimmed
224-Bit User Memory (7 Blocks of 32 bits Each),
OTP Functionality
 64-Bit Unique ID
32-Bit Analog Front End Register

 32-Bit Confi guration Register
Binary Selectable Data Rate (RF/2 to RF/128)
 Modulation/Codings (FSK/PSK/ MAN/Bi-Phase/ NRZ)
 Password Mode
 Inverse Data Output
32-Bit Password (Protection Against Unauthorized Access)
 High Temperature Data Retention (24h at 250ºC)
 Operating Range of –40ºC to +85ºC
Fast Communication Protocols
Self-Timing Downlink Protocols







Packaging & Delivery



Packaging Detail: 200pcs/inner box,10 inner box/carton. G.W.:13KG

Carton Size:520*250*160mm

Delivery Detail: 7-8 days




Payment Term:Paypal.Western Union or T/T in advance
